Texsolv Heddles

Texsolv System heddles are made in joined bundles of 100 (except the 220 and 392 mm sizes which are packaged in a bundles of 40 and 50 respectfully). The strong, durable polyester does not stretch, is knot-free and slides easily on the heddle bar. The open construction of heddles facilitates threading and eliminates warp friction. The heddles are quieter than metal heddles. The material can be dyed to indicate harness sets for easier threading.

Heddle sizes for standard looms are Indicated by the color of the twist ties used to bundle the heddles. To measure your loom for heddles, measure from the top of the top heddle bar to the bottom of the bottom heddle bar. Don’t forget to add the width of the bar for those looms with thicker heddle bars. The complete list of heddle sizes can be found here: https://www.glimakrausa.com/texsolv-master-heddle-list.

All heddles are white and sold in packages of 100 unless otherwise indicated. In sizes where BLUE heddles are available (Louet Spring and David), black, yellow, red, orange and green are also available by special order.

We strongly recommend that you measure your heddle length in millimeters and not inches for greatest accuracy.

150 mm (5 7/8") Red

o   Louet Erica and Standard Inkle

205 mm (8") Black

o   Louet Jane, W40, W70, Kombo, and Magic looms

220 mm (8 5/8”) Green -- Pack of 40

220 mm (8 5/8") Green -- Pack of 100

o   Ashford Inkle, Inklette, Katie and Table Loom

o   Glimåkra band

o   Louet band

o   Schacht inkle

280 mm (11") White

o   Bexell (some Cranbrook Countermarch)

o   Glimåkra Standard

o   Louët David

o   Glimåkra Standard

330 mm (13") Yellow

o   LeClerc (Nilart [12-shaft], Kebec, Colonial)

o   Louët Delta and Octado

o   Norwood Cranbrook 72″

o   Schacht Cranbrook countermarch

o   AVL Studio Dobby and Home Looms

o   Glimakra Cb & CM Extra Shed

390 mm (15 3/8") Brown

o   Louet Spring build before 2018

392 mm (15 1/2") Blue (bundles of 50)

392 mm (15 1/2") Blue (bundles of 100)

o   Louet Megado, Spring, Hollandia
